8″ SB23MFCL-00 / Polyprophylene

PRODUCT COMPARISON

Categories: , ,

Features

  • Long stroke design
  • Linear high stability suspension
  • Low damping rubber surround
  • Very stiff mineral filled Polypropylene cone
  • Rigid cast aluminum chassis
  • Easily adjustable moving mass

Specs

  • Effective piston area, Sd 210 cm2
  • Free air resonance, Fs 19 Hz
  • Compliance, Cms 0.5 mm/N
  • Moving mass incl. air,Mms 141 g
  • Maximum mechanical cone excursion,Xmech ± 19mm
  • Mechanical loss, Rms 1.1 kg/s
  • Mechanical Q-factor, Qms 15.3
  • Equivalent volume, Vas 31.2 liters
  • Net weight 0.89 kg
