5″ SATORI MW13TX-4 / TeXtreme

Features

  • Advanced TeXtreme® cone
  • Vented aerodynamic cast aluminium chassis
  • Soft low damping rubber surround
  • Advanced BIMAX spider
  • Powerful optimized low distortion neodymium motor system
  • Extended copper sleeve on pole piece
  • Non-conducting fiberglass voice coil former
  • Vented pole piece and voice coil
  • Light weight CCAW voice coil
  • Long life silver lead wires

Specs

  • Nominal Impedance 4 Ω
  • DC resistance, Re 3.8 Ω
  • Voice coil inductance, Le 0.16 mH
  • Effective piston area, Sd 70 cm2
  • Voice coil diameter 30.5 mm
  • Voice coil height 15 mm
  • Air gap height 5 mm
  • Linear coil travel (p-p) 10 mm
  • Magnetic flux density 1.08 T
  • Magnet weight 0.1 kg
  • Net weight 0.79 kg
  • Free air resonance, Fs 38 Hz
  • Sensitivity (2.83V/1m) 89 dB
  • Mechanical Q-factor, Qms 5.08
  • Electrical Q-factor, Qes 0.27
  • Total Q-factor, Qts 0.26
  • Moving mass incl. air,Mms 7.4 g
  • Force factor, Bl 5.0 Tm
  • Equivalent volume, Vas 16.0 liters
  • Compliance, Cms 2.38 mm/N
  • Mechanical loss, Rms 0.3 kg/s
  • Rated power handling* 40 W

* IEC 268-5, T/S parameters measured on drive units that are broken in.
