13½″ SATORI WO34HC-8 / Honeycomb
Features
- Rigid honeycomb cone (black fiberglass skin layers)
- Large vented motor system with undercut pole piece and dual shorting rings
- Vented cast aluminum chassis
- Linear symmetric suspension
- Soft low damping rubber surround
- 3″ copper voice coil with non-conductive fiberglass former
- Long life silver lead wires
Specs
- Nominal Impedance 8 Ω
- DC resistance, Re 6.8 Ω
- Voice coil inductance, Le 1.00 mH
- Effective piston area, Sd 585 cm2
- Voice coil diameter 75.6 mm
- Voice coil height 24.6 mm
- Air gap height 8 mm
- Linear coil travel (p-p) 16.6 mm
- Magnetic flux density 1.17 T
- Magnet weight 3.52 kg
- Net weight 9.52 kg
- Free air resonance, Fs 20.2 Hz
- Sensitivity (2.83V/1m) 89.5 dB
- Mechanical Q-factor, Qms 5.37
- Electrical Q-factor, Qes 0.30
- Total Q-factor, Qts 0.29
- Moving mass incl. air,Mms 127 g
- Force factor, Bl 19.0 Tm
- Equivalent volume, Vas 238 liters
- Compliance, Cms 0.49 mm/N
- Mechanical loss, Rms 3.0 kg/s
- Rated power handling* 200 W
* IEC 268-5, T/S parameters measured on drive units that are broken in.
