6½″ SATORI MW16P-12 / Paper

PRODUCT COMPARISON

Categories: , , , ,

Features

  • Vented aerodynamic cast aluminium chassis for optimum strength and low compression
  • Proprietary cone material with EGYPTIAN PAPYRUS™ fibres made in-house
  • Soft low damping rubber surround for optimum transient response
  • Advanced BIMAX spider for improved linearity
  • Powerful optimized low distortion neodymium motor system
  • Non-conducting fibre glass voice coil former for minimum damping
  • Extended copper sleeve on pole piece for low inductance and reduced distortion
  • CCAW voice coil for reduced moving mass
  • Long life silver lead wires attached 180° apart for improved stability
  • Vented pole piece and coil former for reduced compression
  • Low piston to chassis diameter ratio
  • Gasket and bolt hole protrusions for reduced coupling to speaker cabinet

Specs

  • Nominal Impedance 12 Ω
  • DC resistance, Re 10.0 Ω
  • Voice coil inductance, Le 0.19 mH
  • Effective piston area, Sd 119 cm2
  • Voice coil diameter 35.5 mm
  • Voice coil height 17.35 mm
  • Air gap height 5 mm
  • Linear coil travel (p-p) 12.4 mm
  • Magnetic flux density 1.17 T
  • Magnet weight 0.13 kg
  • Net weight 1.01 kg
  • Free air resonance, Fs 30.6 Hz
  • Sensitivity (2.83V/1m) 85 dB
  • Mechanical Q-factor, Qms 4.81
  • Electrical Q-factor, Qes 0.40
  • Total Q-factor, Qts 0.37
  • Moving mass incl. air,Mms 11.5 g
  • Force factor, Bl 7.4 Tm
  • Equivalent volume, Vas 47.3 liters
  • Compliance, Cms 2.35 mm/N
  • Mechanical loss, Rms 0.46 kg/s
  • Rated power handling* 50 W

* IEC 268-5, T/S parameters measured on drive units that are broken in.
