SB14ST-C000-4

SB14ST-C000-4 / Fabric

Categories: , ,

Features

  • Very compact design
  • Excellent piston diameter to OD ratio
  • Large surround for smooth dispersion
  • Threaded rear center hole for easy mounting
  • Long insulated lead wires for versatile integration

Specs

  • Nominal Impedance 4 Ω
  • DC resistance, Re 3.0 Ω
  • Voice coil inductance, Le – mH
  • Effective piston area, Sd – cm2
  • Voice coil diameter 12.4 mm
  • Voice coil height 1.2 mm
  • Air gap height 1.5 mm
  • Linear coil travel (p-p) 0.3 mm
  • Moving mass incl. air, Mms –
  • Free air resonance, Fs 1300 Hz
  • Sensitivity (2.83V/1m) 87 dB
  • Mechanical Q-factor, Qms –
  • Electrical Q-factor, Qes –
  • Total Q-factor, Qts –
  • Force factor, Bl – Tm
  • Rated power handling* 10 W
  • Magnetic flux density 0.97 T
  • Magnet weight 3.4 g
  • Net weight 0.014 kg
    *IEC 268-5, high-pass Butterworth, 2600 Hz, 12 dB/oct
