8in SB23NRXS45-8

8″ SB23NRXS45-8 / Norex

Categories: , , ,

Features

  • Soft low damping rubber surround for improved transient response
  • Shorting ring in motor system for reduced distortion
  • Vented pole piece for reduced compression
  • Vented cast aluminum chassis for optimum strength and low compression
  • Shallow design
  • Non-conducting fiber glass voice coil former for minimum damping
  • CCAW voice coil for reduced moving mass
  • Long life silver lead wires

Specs

  • Nominal Impedance 8 Ω
  • DC resistance, Re 5.6 Ω
  • Voice coil inductance, Le 0.60 mH
  • Effective piston area, Sd 216 cm2
  • Voice coil diameter 45.5 mm
  • Voice coil height 19 mm
  • Air gap height 6 mm
  • Linear coil travel (p-p) 13 mm
  • Magnetic flux density 0.86 T
  • Magnet weight 0.8 kg
  • Net weight 2.74 kg
  • Free air resonance, Fs 27 Hz
  • Sensitivity (2.83V/1m) 88.5 dB
  • Mechanical Q-factor, Qms 5.4
  • Electrical Q-factor, Qes 0.41
  • Total Q-factor, Qts 0.38
  • Moving mass incl. air,Mms 24.5 g
  • Force factor, Bl 7.5 Tm
  • Equivalent volume, Vas 94 liters
  • Compliance, Cms 1.42 mm/N
  • Mechanical loss, Rms 0.77 kg/s
  • Rated power handling* 60 W

* IEC 268-5, T/S parameters measured on drive units that are broken in.
